PIMS is to provide a current status report in respect of physical parts (generally pipes) of the pipeline. Items included in addition to pipes are bends, valves, assemblies, joints and tees.
During the lifetime of the GIGL pipelines, PIMS will keep track of the information related to the constituent parts of the GIGL pipelines (Pipes, Bends, Valves, Assemblies, Joints, Tees, Reducers) readily accessible.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
Business Objective
Project Name : Development VLCC jetty at Mundra for handling crude imports
| Project Name | : | Development VLCC jetty at Mundra for handling crude imports | |
| Project Length | : | 12.3 Km | |
| Material Specification | : | API 5L Gr. X-52, PSL-2, SAWL/SAWH | |
| Diameter | : | 48” | |
| Wall Thickness (mm) | : | 9.53 | |
| Coating | : | 3LPE | |
| Client | : | HOWE ENGINEERING PROJECTS (INDIA) PVT. LTD. | |
| Consultant | : | Valdel Engineers & Constructors Pvt. Ltd. |  |
| Contractor | : | JAI SHAKTI ENGINEERING AND CONSTRUCTION |  |
| PIMS | : | Unistal Systems Pvt. Ltd. |  |
| Start Date | : | 11.02.2022 | |
| End Date | : | 30.11.2022 |
| Spread | Section | Chainage From | Chainage To | Length |
|---|---|---|---|---|
| Spread 1 | Jetty to railway crossing | 0.0km | 5.552 KM | 5.552 |
| Spread 2 | Railway crossing to PUB road crossing | 5.552 | 8.653 | 3.101 |
| Spread 3 | PUB road crossing to IOCL terminal | 8.653 | 12.3 | 3.647 |
�
Services By Unistal System Pvt. Ltd.
